Marstek M2200 – 2240Wh LiFePO4 Power Station
The Marstek M2200 is a powerful and versatile portable home battery with an impressive 2240Wh capacity. This power station is ideal for off-grid use, camping, work vans, or as a backup power source at home. Thanks to its robust LiFePO₄ battery technology, the M2200 offers safety, a long lifespan, and high performance.
Key Features
- Capacity: 2240Wh (LiFePO₄) – expandable to 6720Wh with additional modules
- AC Output: 4x AC outlets up to 2400W continuous / 4800W peak
- Smart Power Control (SPC): automatically adjustable up to 2800W output power
- Input: Up to 2000W via AC & 1200W via solar panel (MPPT)
- USB-C: 1x 100W + 1x 45W, USB-A: 2x 18W
- 12V car plug (10A) + 5521 DC outputs
- UPS function: switches on within
- Lifespan: more than 6000 charging cycles
- Safe: equipped with a 6-way Battery Management System (BMS)
Applications
The Marstek M2200 has a wide range of applications:
- At home: as an emergency power supply or energy storage
- Off-grid: in tiny houses, cabins or at the campsite
- Construction & mobile work: for power tools or workstations without a mains connection
- Campervans and buses: ideal in combination with solar panels
Recommended solar panel
For optimal off-grid use, we recommend combining the Marstek M2200 with the powerful Voltero S420 foldable solar panel (420W) . This panel is compact, efficient, and perfectly matched to the M2200.
Benefits of LiFePO₄ technology
- High thermal and chemical stability
- Longer life than lithium-ion: >6000 cycles
- Reliable and safe for long-term use
Technical specifications
- Capacity: 2240Wh (LiFePO₄)
- AC output: 2400W (SPC 2800W) / 4800W peak
- AC input: 2000W (fast charging)
- Solar panel input: 1200W max, 2x MPPT DC input
- USB-C: 1x 100W PD + 1x 45W
- USB-A: 2x QC3.0 18W
- UPS function: changeover
- Dimensions: approx. 50 x 28 x 31 cm
- Weight: approx. 26.7 kg
In the package
- 1x Marstek M2200 Power Station
- 1x AC charging cable
- 1x MC4 to XT60 solar panel adapter
- 1x Manual (NL/EN)
NB
Due to its large battery capacity, air transport is not permitted. The M2200 is intended for road or sea transport only.
Frequently Asked Questions (FAQ)
1. Can I use the Marstek M2200 as a home battery?
Yes, the M2200 is ideal as an emergency power source for your home. Thanks to its UPS function, it automatically switches over in the event of a power outage and can continue to power appliances such as refrigerators, routers, and lighting.
2. How quickly does the Marstek M2200 fully charge?
With a 2000W AC charger, charging from 0% to 80% takes about 1.2 hours. A full charge takes approximately 1.8 hours. Solar charging (1200W input) takes an average of 2-4 hours, depending on sunlight.
3. Can I combine the Marstek M2200 with solar panels?
Absolutely. The M2200 supports up to 1200W of solar panel input via MPPT. For optimal performance, combine it with the Voltero S420 foldable solar panel .
4. Is the Marstek M2200 safe to use indoors?
Yes. Thanks to its LiFePO₄ chemistry, built-in BMS protection, and quiet operation, the M2200 is safe for use in your home, shed, camper, or office.
5. How many devices can I connect simultaneously?
You can connect up to four 230V devices to the AC outlets, plus several more via USB and DC outlets. The total power must not exceed 2400W (or 2800W with SPC).
6. Is the battery replaceable or upgradeable?
The built-in battery is not replaceable, but you can expand it with additional Marstek modules up to a maximum of 6720 Wh. Contact us for compatible expansion kits.
7. Can I take the M2200 with me on holiday or in the car?
Yes, that’s possible. The M2200 is suitable for mobile use in cars, campers, or work vans. However, please be aware of its weight (approx. 26.7 kg) and that air transport is not permitted due to its large capacity.
8. How long does the battery last?
The LiFePO₄ battery is designed for over 6,000 charge cycles. This means a lifespan of 10 years or more with daily use.
